Ports and op erati ng eleme nts
Module
ModulebayModule
The design of your notebook enables the flexible use of noteb ook batteries and drives. The
following modules can be opera ted in the module bay of your notebook:
• DVD Super Multi
• Second battery
• Blind insert (Weight Saver)
Only use modules designed for your notebook.
Do not use force when installing or remo ving the module.
Make sure that no foreign objects enter the module bay.
You can swap modules during operation. This means you do not
need to switch off the n otebook.
To replace a module, simply click on the corresponding icon in the
task bar and then on Exit or Select - Exit.
The module can now be removed without any further actions being necessary.
Removing a module
1
2
ModuleDriveWei ghtSaver
► Press the release mechanism (1) in the direction of the arrow and hold.
► Now pull the module (2) out of the mod ule bay.
18 A26391-K198-Z121-1-7619, edition 2
