22
Using the Active Digitizer
The integrated Active Digitizer allows you to use
the included pen as a pointing device. You can
use the pen to click, double-click, drag items and
icons, or to draw like a pen or pencil in
applications that support this behavior, such as
drawing or painting programs. See the
documentation that came with your application
for details.
(Figure 2-27)
Figure 2-27. Using the pen with the Screen
To avoid potential scratching and damage,
never use anything but the included pen with
the display.
Clicking
To left-click, touch the object you wish to select
and then lift the pen tip immediately.
(Figure 2-28)
To right-click, press the front button on the barrel
switch or touch the pen to the screen for a couple
of seconds until the right mouse icon appears at
the tip.
Figure 2-28. Clicking the Screen
Double-Clicking
To double-click, touch the item twice, and then
immediately remove the pen tip.
(Figure 2-29)
Figure 2-29. Double-clicking the screen
If the interval between taps is too long,
the double-click will not be executed.
Parameters for the Touch Screen can be
adjusted from the Mouse Properties
dialog box located in the Windows Control
Panel.
LB_Soriel 03 (20-22) 26/11/04, 3:32 PM22
