38
5. Remove the memory upgrade module from the
static guarded sleeve.
6. Align the memory upgrade module with the
component side up. Align the connector edge
of the memory upgrade module with the
connector slot in the compartment.
(Figure 4-
3)
7. Insert the memory upgrade module at a 45°
angle. Press the connector edge of the module
firmly down and into the connector until it
lodges under the retaining clip. You will hear a
click when it is properly in place.
Figure 4-3. Installing a Second Memory Module
8. Replace the cover.
(Figure 4-4)
9. Replace the screws.
Figure 4-4. Replacing the Memory
Compartment Cover
The memory upgrade module is not
something you routinely remove from your
notebook. Once it is installed, you should
leave it in place unless you want to change
system memory capacity.
Memory Upgrade Module
Your Fujitsu LifeBook T Series Tablet PC comes
with a minimum of 256 MB of high speed Double
Data Rate Synchronous Dynamic RAM (DDR
SDRAM), 333 MHz factory installed. To increase
your system’s memory capacity, you may install
an additional memory upgrade module. The
memory upgrade must be a dual-in-line (DIMM)
SDRAM module. To ensure 100% compatibility,
purchase the SDRAM module only from the
Fujitsu store.
Do not remove any screws from the memory
upgrade module compartment except those
specifically shown in the directions for
installing and removing the memory upgrade
module.
Installing Memory Upgrade Modules
1. Turn off power to your Tablet PC and remove
any attached power adapter.
2. Make sure that all connector covers are closed.
3. Turn the Tablet PC bottom side up, and remove
the screws of the memory upgrade module
compartment.
(Figure 4-2)
4. Remove the cover.
Figure 4-2. Opening the Memory Upgrade
Compartment
Slot 1
Slot 2
LB_Soriel 06 (33-42) 26/11/04, 3:34 PM38
