2.2.2 Appearance
Figure 2.1 shows an optical disk cartridge. The names of the components of an
optical disk cartridge are also shown.
(a) Shutter closed
Figure 2.1 Optical disk cartridge (1 of 2)
(b) Shutter open
Figure 2.1 Optical disk cartridge (2 of 2)
(4) Disk
(5) Hub
(1) Cartridge case
(2) Shutter
(3) Write protect tab
