4.3 Settings
C156-E228-02EN 4-11
4.3.3 SCSI terminating resistor mode
Enabling or disabling the SCSI terminating resistor, module on the PCA can be
set.
When the drive positions at other than the end of the SCSI bus, the SCSI
terminating resistor should be disabled. Table 4.7 shows the SCSI terminating
resistor mode setting.
Table 4.7 SCSI terminating resistor mode (CNH1)
SCSI terminating resistor mode CNH 1 05-06
SCSI terminating resistor module on the PCA is enabled. Short (*1)
SCSI terminating resistor module on the PCA is disabled. Open
*1 Setting when shipped
Note:
Open CNH1 5-6 pins when the SCSI terminating resistor set by CHN 2-15 pin.
