5.3 Operation of Optical Disk Cartridge
C156-E228-02EN 5-7
(a) Shutter closed
(b) Shutter open
Figure 5.4 Appearance of optical disk cartridge
(3) Write protect tab
(1) Cartridge case
(2) Shutter
(
5) Hub
(
4
)
D
isk
