Getting started
Removing monitor base
Before you can use a swivel arm or a wall bracke t, you must remove the monitor base.
The display surface is susceptible to scratching!
1
1
1
1
► Switch off the monitor and pull the power
plug out of the power socket.
► Lay the monitor on its face on a soft surface.
► Remove the cover and disconnect all cables.
► Remove the screws (1) on the rear
of the mon itor.
You can now mount a sw ivel arm or a wall
bracket in accordance with VESA FPMPMI
using a hole spacing of 100 mm.
For instructions on how to mount the swivel arm or wall bracket, please see
the documen tation for the swivel arm or w all bracket.
Fujitsu Technology Solutions 15
