Techn ical specification
Environmental conditions
Environment class 3K2, DIN IEC 721
Rated range o f op eration
Humidity
15 °C .... 35 °C
20 % .... 85 %
Limit range of operation
Humidity
5 °C .... 35 °C
20 % .... 85 %
VESA-DDC-compatible VGA interface
Your monitor is equipped with a VESA-DDC-compatible VGA interface. VESA-DDC (Video
Electronics Standard Association, Display Data Channel) is used as the communications
interface between the monitor and the c ompu ter. If the computer is equipped with a
VESA-DDC-compatible VGA interface, it can automatically read the data for ensuring
optimum operation from the monitor and select the appropriate settings.
Preset operating modes
The picture posit
ion an d size have been set to optimum values at the factory for the
operating modes l
isted above. Depending on the display adapter used, it may be
necessary to adj
ust the display position and size. In th is case, you can change and
save the settin
gs (see chapte r "
Changing the monitor settings", Page 2 0).
For ergonomic r
easons, a screen resolution of 1920 x 1080 pixels is recommended.
Because of the
technology used (active matrix), an LCD monitor provides a
totally flicke
r-free picture, even w ith a r efresh rate of 60 Hz.
Most frequent operating m odes
Horizontal frequency Refresh rate Screen resolution
31.5 kHz 70 Hz 720 x 400
31.5 kHz 60 Hz 640 x 480
37.5 kHz 75 Hz 640 x 480
37.9 kHz 60 Hz 800 x 600
46.9 kHz 75 Hz 800 x 600
48.4 kHz 60 Hz 1024 x 768
55.4 kHz 60 Hz 1440 x 900
60.0 kHz 75 Hz 1024 x 768
64.0 kHz 60 Hz 1280 x 1024
65.0 kHz 60 Hz 1680 x 1050
67.6 kHz 60 Hz 1920 x 1080
74.0 kHz 60 Hz 1920 x 1200
80.0 kHz 75 Hz 1280 x 1024
Fujitsu Technology Solutions 33
