Getting s tarted
Connecting the device
Please observe the safety information in "Important notes", Page 7.
CE conformance and optimum pict ure quality are guaranteed only i f
you use the data cables supplied.
► Switch off the monitor and the c omputer.
► Disconnect the power plug
from the computer.
Connecting cables to the monitor
The monitor ports are pr
otected by a cover.
The supplied data cable
s ha ve two 15-pin D-SUB connectors or two 24-pin DVI co nnectors
or two 2 0-pin DP-conne
ctors for connection to the monitor and to the computer.
Information on the co
mputer connections and interfaces is contained in the
operating manual fo
r the computer.
345 678910
10
1
2
1=Securi
ty slot for "Kensington Lock"
2 = Cover
3=Power
connector
4 = 0 W switch
5 = Disp
lay Port (DP) connection socket
6=DVI-Ds
ocket (DVI)
7 = D-SUB socket (VGA)
8 = AUDIO
-IN socket
9 = USB IN ( Downstre am)
10 = USB O
UT (Upstream)
► Remove the cover.
► Select th e ap propriate data cable for your computer.
16 Fujitsu Technology Solutions
