Fujitsu P24-9 TE User Manual

Important notes
• The device may only be operated in wide format (0° landscape mode) and high format
(90° portrait mode). The buttons of the control panel are located at the bottom in
the middle of the monitor in wide format (0° landscape mode) and at the left-hand
side of the monitor in high format (90° portrait mode).
• Store this manual close to the device. If you pass the device on to third
parties, you should pass this manual on with it.
• We recommend that you place your device on a durable, non-slip surfa ce. In view
of the many different finishes and varnishes used on furniture, it is possible that the
feet of the device may mark the surface they stand on.
• The device must be connected to protect ive earth.
• To prevent possible hearing da m age, do not listen at high volume levels for long pe riods.
• Warning for excessive sound pressure from earphones and headph ones:
Excessive sound pressure from earphones and headphones can cause hearing loss.
Adjustment of the equalizer to maximum increases the earphones and hea dphones
output voltage and therefore the sound pressure level.
Power supply unit
To prevent the risk of fire, the monitor must only be operated with the original
power supply Delta ADP-180MB K - 19.5V/9.23A.
The supplied AC/DC power supply must only be connected to monitor.
Power cable
Use the supplied power cable only.
Use the following guidelines if it is necessary to replace the original cable set.
• The female/male recep tacles of the cord set must meet I EC 60320/C E E-22 requirements.
• The cable h
as to be HAR-certified or VDE-certified. The mark HAR or
VDE will a
ppear on the outer sheath.
• For devices which are mounted on a de sk or table, type SVT or SJT cable sets may be
used. For de vices which sit on the floor, only SJT type cable sets may be used.
• The cabl
e set must be selected according to the rated current for your device.
• If necessary, replace the original power cable with a regular grounded 3-core ma ins lead.
8 Fujitsu

Fujitsu P24-9 TE Specifications

General

3D	No
Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
Display diagonal	23.8 \
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 76 Hz
Horizontal scan range	30 - 82 kHz
Supported video modes	720p, 1080p
Viewable size, vertical	296 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	527 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Tilt angle range	-5 - 35 °
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, NOR, POL, RUS, SWE, TUR
TV tuner integrated	-
RMS rated power	4 W
Number of speakers	2
USB upstream port type	USB Type-C
USB Type-A downstream ports quantity	3
USB Type-C downstream ports quantity	1
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	21 W
Power consumption (off)	0.26 W
Annual energy consumption	28 kWh
Power consumption (standby)	- W
Power consumption (typical)	19 W
Power consumption (PowerSave)	0.3 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR
Certification	CE, FCC, TÜV GS
Product color	Gray
Package type	Box
Package weight	7200 g
Cables included	AC, DisplayPort, USB

Weight and Dimensions

Depth (with stand)	229.3 mm
Height (with stand)	347 mm
Weight (with stand)	5300 g
Depth (without stand)	63.1 mm
Width (without stand)	540.3 mm
Height (without stand)	325.6 mm
Weight (without stand)	3300 g
