Notes on power management
Notes on power management
If your computer is equipped with power mana gement (power-saving mode), the monitor can fully
support this function. Here the monitor does not distinguish between the individual energy-saving
modes of the computer (standby mode, suspend mode and OFF mode), a s it is capable of
immediately switching into the m ode with the highest energy-saving effect.
Stage Operation
Power saving mode
Normal
ECO
Power supply indicator Lights up blue Lights up green Lights up orange
Display Max. brightness
typ. 175 cd/m
2
unlit
Typical power
consumption (without
USB and audio)
<21W <18W <0.5W
If the computer detects inactivity (no input) it sends an appropriate signal to the monitor to reduce
the power consumption (power saving mode) . The power indicator of the monitor changes
colour to show the change in status. ECO mode is the preset factory default.
Once an input is made at the computer the screen contents are restored.
For detailed information on how energy-saving mode operates, please refer to
the operating manual or technical manual of the comput er.
Fujitsu 39

Fujitsu P24-9 TE Specifications

General

3D	No
Pixel pitch	0.2745 x 0.2745 mm
Screen shape	Flat
Display diagonal	23.8 \
Display technology	LCD
Native aspect ratio	16:9
Vertical scan range	48 - 76 Hz
Horizontal scan range	30 - 82 kHz
Supported video modes	720p, 1080p
Viewable size, vertical	296 mm
Contrast ratio (dynamic)	20000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	527 mm
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Tilt angle range	-5 - 35 °
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, NOR, POL, RUS, SWE, TUR
TV tuner integrated	-
RMS rated power	4 W
Number of speakers	2
USB upstream port type	USB Type-C
USB Type-A downstream ports quantity	3
USB Type-C downstream ports quantity	1
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	21 W
Power consumption (off)	0.26 W
Annual energy consumption	28 kWh
Power consumption (standby)	- W
Power consumption (typical)	19 W
Power consumption (PowerSave)	0.3 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	10 - 85 %
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR
Certification	CE, FCC, TÜV GS
Product color	Gray
Package type	Box
Package weight	7200 g
Cables included	AC, DisplayPort, USB

Weight and Dimensions

Depth (with stand)	229.3 mm
Height (with stand)	347 mm
Weight (with stand)	5300 g
Depth (without stand)	63.1 mm
Width (without stand)	540.3 mm
Height (without stand)	325.6 mm
Weight (without stand)	3300 g
