16 Operating Manual BX900S2
Functional overview
© cognitas. Gesellschft für Technik-Dokumentation mbH 2012 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-13566-001.fm
PRIMERGY SX980 S1 storage blade
Storage media 2.5 inch HDD or SSD modules
Disk slots quantity 10
Max. per system unit 3
Installable in slots 1/2 - 3/4 - 5/6 - 7/8 - 9/10 - 11/12 -
13/14 - 15/16
Connected to server blades with SAS
mezzanine card via SAS
connection blade
PRIMERGY SX980 S2 storage blade
Storage media 2.5 inch HDD or SSD modules
Disk slots quantity 10
Max. per system unit 3
Installable in slots 1/2 - 3/4 - 5/6 - 7/8 - 9/10 - 11/12 -
13/14 - 15/16
Connected to server blades with SAS
mezzanine card via SAS
connection blade
I This storage blade provides dual port / redundant SAS
connections to the SAS drives.
