BX900S2 Operating Manual 29
Functional overview
2.2 System unit specification
This section explains the specifications for the system unit. The specifications
for this system unit are liable to be updated without any notice. Please be
forewarned.
Interfaces (Management Blade)
Slots
Operating Panel
USB connectors 2 x
Serial 1 (9-pin) 1 x serial RS-232-C
Management LAN (RJ-
45)
Management LAN ports for blade server
management (2 x 1 Gbit/s Ethernet)
Service LAN (RJ45) Dedicated Service LAN port for MMB (1 Gbit/s
Ethernet)
Dual Server Blades or
Storage Blades
18 x
Management Blades 2 x
Connection Blades 8 x (2 per 4 fabrics)
PSU 6 x
Operating buttons On/off button
ID button
Status LEDs ID indicator (blue)
Power indicator (orange / green)
Global Error indicator (orange)
CSS indicator (yellow)
Service Display ServerView Local Service Display for Blade
