BX900S2 Operating Manual 75
Starting up and operation
7, 9 LAN link indicators (Management LAN ports)
Lights up green if a LAN connection exists.
Does not light up if no LAN connection exists.
8, 10 LAN activity indicators (Management LAN ports)
Flashes yellow when a LAN transfer is in progress.
Does not light up if no LAN transfer.
11 Reset button
