82 Operating Manual BX900S2
Starting up and operation
© cognitas. Gesellschft für Technik-Dokumentation mbH 2012 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-13570-001.fm
A HiGig/HiGig+ connection (CX4) for stacking (2x), for detailed information see the
"PRIMERGY BX900 S2 System Unit Upgrade and Maintenance Manual"
B 10-Gbit Ethernet ports for SFP+ modules for connecting fiber-optic or copper
cables (with two integrated status LEDs each)
6 (ERR) Error indicator (orange)
Dark: No SFP+ transceiver error
Lit: SFP+ transceiver error
Flashes: SFP+ module not supported
7 (LINK) LAN connection indicator (green)
Lit: SFP+ transceiver connection available
Flashes: SFP+ transceiver connection active
Dark: SFP+ transceiver connection not available or
deactivated.
C 1-Gbit Ethernet ports (RJ45 with two integrated LAN status LEDs each)
8 LAN transfer rate (green/orange)
Lights up
orange:
LAN transfer rate 1 Gbit/s
Lights up green: LAN transfer rate 100 Mbit/s
Dark: LAN transfer rate 10 Mbit/s
9 LAN connection indicator (green)
Lit: LAN connection available
Flashes: LAN connection active
Dark: LAN connection unavailable or deactivated
