RX300 S3 Options Guide 105
14 Appendix
14.1 Cabling
The following table gives you an overview of the cables:
*refers to the drawings of the cabling
Cable
# *
Part number Item number Designation Lengt
h/mm
1 S26361-F3120-V2 Parallel port 310
2 T26139-Y3694-V103 A3C40071653 PS 20 pol 280
3 T26139-Y3758-V7 A3C40057188 PS 24 pol 250
4 T26139-Y3939-V101 A3C40068169 PS SAS backplane
/CDD
700
4b T26139-Y3939-V111 A3C40085560 PS Expander-Board-
CDD
1200
5 T26139-Y3925-V201 A3C40068188 Front panel 250
6 T26139-Y3662-V303 A3C40057187 ULTRA ATA 100
7 T26139-Y3696-V12 A3C40057186 FDD 150
8 T26139-Y3718-V105 A3C40039940 SMB 650
9 S26361-F3120-V3 Serial port 300
10 T26139-Y3906-V7 A3C40057182 Hot-plug 120
11 A3C40083827 USB 400
12 T26139-Y3959-V201 A3C40074671 SV tape drive 270
