RX300 S3 Options Guide 91
12 Converting from low-profile to
standard PCI Slots
V CAUTION!
Observe the safety instructions in the chapter “Safety notes” on page 15.
12.1 Removing lp slot cage
Ê Open the server as described in the chapter “Preparation” on page 21.
Figure 75: Removing hot-plug cable
Ê Release and remove the hot-plug cable from the system board.
