5.1.3.2 HDD backplane for 8 x 2.5“ HDDs
Part number: A3C40093253
Figure 46: Power Backplane
Connector Description
X1 SAS channel 1
X2 SAS channel 2
X9 Power input
X4 Power output
X1X2 X11X12
