60 Service Supplement RX300 S5
Board layouts Appendix
5.1.4 IDTemp Combo
Part number: A3C40096564
Figure 48: IDTemp Combo
5.1.5 PCI SAS controller
5.1.5.1 SAS IME controller
Figure 49: PCI eXpress LSI 1068 (Modular RAID IME) Controller
Connector Description
X1 SMB
X1
