FUJITSU PSWITCH 4032P
LED
LED status
Condition
System LED
Off
Power is off
Solid Green
Normal operation
Blinking Green
Booting in progress
Solid Yellow
Major faults, the faults are traffic affecting
Blinking Yellow
Minor faults, the faults are not traffic affecting
Power LED
Off
Power is disconnected
Solid Green
Operating normally (Dual or Single Supply)
Solid Yellow
POST in progress
Blinking Yellow
One of Power Supplier is failed
Fan LED
Solid Green
FAN operating normally
Solid yellow
FAN is failed including incompatible airflow direction
Located LED
Off
No power or the locator function is disabled.
Blinking Blue
The locator function is enabled
40G QSFP slot
LEDs
Off
No link (Link LED)
Solid Green
A valid 10G/40Gbps link (Link LED)
Blinking Green
10G/40G speed, Packet transmission or reception in
progress (ACT LED)
Management
Port LEDs
Off
No link is established on the port
Solid Yellow
A valid link at 10/100Mbps is established on the port
(Link LED)
Solid Green
A valid link at 1000Mbps is established on the port
(Link LED)
Blinking Green
Activity, transmitting or receiving packet at this port
(ACT LED)
Table 1-2: Front LED status (FUJITSU PSWITCH 4032P)
FAN LED on the front panel will be yellow when one of the FAN LEDs at the
rear side fails.
