User’s Guide FUJITSU PSWITCH
December/2018 179
6 Hardware Specification
FUJITSU PSWITCH 2048T
Item
Description
Key components
Switch controller
BCM56854 x 1
PHY
BCM54616S x 1 (for console Management port)
CPU
Intel Rangeley C2338 Processor
Flash
16MB SPI x 2
Storage
8GB mSATA SSD
System memory
4GB DDR3-SDRAM
Network Protocol and Standards Compatibility
Network protocol/
compatibility
IEEE 802.3 10Base-T on management port
IEEE 802.3u 100Base-TX on management port
IEEE 802.3ab 1000BASE-T on management port
IEEE 802.3x Flow-Control
IEEE 802.3z 1000BASE-X
IEEE 802.3ae 10Gb/s Ethernet
IEEE 802.3ba: 40Gb/s Ethernet
Interface Information
Interface
10G BASE-T RJ45 port x 48
Quad Small Form-factor Pluggable (QSFP) slot x 6
10/100/1000Mbps Management port x 1
External Console port (RJ45) x 1
USB port x 1
Reset button x 1 (out of support coverage)
Micro USB console port x 1 (out of support coverage)
Power Supply Unit (AC/DC)
Max. output power
460W
Input voltage
AC 100 ~ 240V
Output voltage
DC 12V
Physical
Dimensions (W x D x H)
440 x 460 x 44 mm (17.32 x 18.11 x 1.73 inch)
Weight
10.4 kg (Included PSU x2)

Fujitsu PSWITCH 2048P Specifications

General

Brand	Fujitsu
Model	PSWITCH 2048P
Category	Switch
Language	English
