Example: iX1600
ATTENTION
l Do not accumulate more than 50 sheets (with paper weight of 80 g/m
2
[20 lb]) in the stacker.
l When the [Place document face up] checkbox is selected in the [Scanning mode option]
window, load the documents face-up and bottom edge down.
To open the [Scanning mode option] window, click the [Option] button in the [Scanning] tab of
the "ScanSnap Setup Window" (page 89).
Example: iX1600
7. Adjust the side guides to the width of the documents.
Hold each side guide in the middle to adjust them. Otherwise, the documents may be fed
skewed.
Example: iX1600
Scanning Documents with iX1600 / iX1500 / iX1400
187
