102
4. Remove the sheet guide.
Pinch the handle and claw together on both sides of the sheet guide to remove it.
5. Rotate the Pick roller bushing (on the left side).
Sheet guide
Claw
Handle
Pick roller Pick roller bushing
Pick roller shaft
