5-3
Chapter 5 12-Lead Examination Type of Waveform Recording/Printing
While printing compressed waveform
*1: Displayed only when there is a previous examination.
*2: By touching [Hold], extended recording/printing of the lead block currently being recorded/printed will be
performed. (
"Extending Printing" P5-16)
Type of Waveform Recording/Printing
The following types of printing are available.
Printing Format for Auto Printing
The printing format for auto printing is composed of the following.
Waveform Report
Waveform report settings can be configured under [Setting] > [12 Lead Exam.] > [12-Lead Auto Print] >
[Waveform Report]. Settings such as the waveform recording time, waveform report output and waveform
report format can be configured.
(
"Waveform Report" P13-20)
Measurement Result Report
For the result reports, "Cover", "DOM1", "DOM2", "DOM3", "FULL3", "FULL6", "Panorama", "Time
Comparison" are available.
The printing details can be configured under [Setting] > [12-Lead Exam.] > [12-Lead Auto Print] > [Result
Report]. Refer to
"Examples of Printing" P5-6 for printing details of the DOM1 report, printing procedure
of detailed measurement report, etc.
ACS Summary Report
ACS Guide Report
Brugada Risk Analysis Report.
Analysis Report
Commentary Report
Detailed Measurement Report
To print detailed measurements, set "Yes" for "Det. Meas. Report" under [Setting] > [12-Lead Exam.] > [12-
Lead Auto Print] > [Result Report 1]. (
"Results Report" P13-20)
Refer to
"12-Lead Examination" P13-15 for setting the printing method of each report.
When an optional software is installed, analysis result report will be recorded/printed instead
of measurement result report during the auto recording/printing.
Mark End
Auto Printing ECG waveform is printed in a fixed format according to the preset items.
(
"Recording/Printing Automatically" P5-4)
Review Printing ECG waveform is printed for the specified period until the (Review) key is pressed.
(
"Printing Waveforms from Several Seconds Before (Review Recording/Printing)" P5-13)
Manual Printing ECG waveform is printed manually while changing lead and sensitivity freely as necessary.
(
"Manual Recording/Printing" P5-10)
Waveform
Report
Measurement
Result Report
ACS Summary
Report
ACS Guide
Report
Analysis Guide
Report
Commentary
Report
Detailed
Measurement
Report
To Next Page
