On - turned on;
Off - turned off
Def - defrost
Thermostat on display:
Trm1: Individual thermostat 1
Trm2: Individual thermostat 2
Trm3: Individual thermostat 3
Control output status
Defrost output status
Operation mode:
A: heating
R: refrigeration
Control temperature value
Temperature setpoint
12.SUMMARY SCREEN
12.6. Individual thermostats:
The individual thermostat screens are accessed from the Control Menu
To toggle between the available pressure switches just navigate using the keys and .
1
7
5
4
6
Trm1
On
2
3
R
Setpoint: 20.0 °C
Temp: 15.4°C
Output: Off
Defrost: Off
