18.MAIN MENU
18.2 System settings
2.1 Pressure measurement unit:
Pressure measurement unit used by the controller: Psi or Bar.
2.2 Temperature measurement unit:
Temperature measurement unit used by the controller: Celsius or Fahrenheit.
2.3 Language:
Controller language: Portuguese, English or Spanish.
2.4 Buzzer:
Enables the audible warning function in case of alarm and controller feedback.
2.5 Enables display eco mode:
Enables display sleep mode. After a period of 15 minutes the display brightness decreases, increasing its life span and decreasing energy
consumption.
2.6 Preferred pressure display:
By default, the RCK-862 plus uses pressure data to perform the control. There is an option to change the display to the temperature (°C or °F)
corresponding to the saturation of the refrigerant. If the refrigerant has not been configured in the groups menu and the preferred temperature display is
changed, the message ‘’cfg’’ is displayed.
Note: If the pressure read by the sensor is equivalent to a region outside the sub-critical, the message ‘’PC’’ is displayed, indicating that the
value is above the critical point.
Note: When ECO mode is active, just a short press on any of the keys will disable it.
Feature
Minimum
Maximum Unit
Standard
Description
°F
bar
°C °C
Psi Psi
-
-
-
Portuguese
Portuguese
2.1
2.2
2.3
2.4
2.6
2.5
Spanish
Yes
Yes
-No
0
0
-1
Temperature measurement unit
Warning sound (Buzzer)
Preferred pressure display
Pressure measurement unit
Enable display eco mode
Language
Yes
Yes
-No
0 = Pressure
1 = Temperature
18.3 Communication settings:
The RCK-862 plus has two independently configurable RS-485 communication ports for communication with the Sitrad software or
supervisory ones that use the MODBUS protocol.ie
3.1
Rs485 - 1: Protocol
Rs485 - 1: Address
RS485 - 1: Baud rate
Rs485 - 1: Parity
Rs485 - 2: Address
RS485 - 1: Stop bits
RS485 - 2: Baud rate
Rs485 - 2: Protocol
Rs485 - 2: Parity
RS485 - 2: Stop bits
3.2
3.3
3.4
3.7
3.5
3.8
3.6
3.9
3.10
0
1 247
1
5
0
1
2
5
2
2
2
0
1
0
0
1
247
5
2
2
1
5
0
1
0
1
1
0
-
-
-
-
-
-
-
-
-
2
Feature
Minimum
Maximum Unit
Standard
Description
44
