18.MAIN MENU
Note: To perform this procedure, the control status must be in OFF mode.
Note: Administrator access level is required to perform this procedure.
18.5 Data management:
The RCK-862 plus has a USB port with support for communication via pen drive, where it is possible to manage recipes and update the controller
firmware. Access path: Main Menu Data manager. ddd
18.5.1 Export recipe RCK-862 plus Pendrive (5.1):
Copies the recipe from the controller to the memory of the Pen drive.
The file will be stored in the RCK-862 folder and will be named according to the following logic:
MODEL_AAMMDD_HHMMSS.rec, where:
MODEL = product model, AA = year, MM = month, DD = day, HH = hour, MM = minute, SS = second.
Example: A recipe exported on an RCK-862 plus, on 08/02/2019 at 13:30:00 will have the name RCK-862_190802_133000.rec.
18.5.2 Import recipe RCK-862 plus Pendrive (5.1):
Copies the recipe from a pen drive to the controller memory.
RCK looks for the recipe in the RCK-862 folder. The recipe name can be a maximum of 32 characters, including the extension (.rec).
Note: The RCK-862 folder must contain a maximum of 32 recipe files.
18.5.3 Firmware update (5.3):
Updates the controller firmware.
The file must be inside the RCK-862 folder and its name must have a maximum of 32 characters, including the extension (.ffg)
Note: The folder must contain a maximum of 32 firmware files.
18.6 Restore factory default:
Restores all parameters to the settings to factory defaults. Access path: Main Menu 6. Restore Factory Default.dd
47
