2015/06/19 13-2 A4AF0_EL
Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DIGITAL MAIN CBA UNIT
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT A4AF0MMA-006
Following parts can be supplied.
CAPACITORS
C602# CAP CERAMIC SAFETY 1000pF/250V E M KX CJMR102M42E1
C603# CAP CERAMIC SAFETY 1000pF/250V E M KX CJMR102M42E1
C604# CAP METALLIZED FILM 0.22µF/275V/K CTA224PKR001
C605 CAP ELE 330µF/200V/M/85 CEA3310S6016
C606 CERAMIC CAP. 820pF/2kV CA3D821PAN04
C607 CHIP CERAMIC CAP. B K 1800pF/50V CHD1JK30B182
C608 CHIP CERAMIC CAP.(1608) B K 0.015µF/50V CHD1JK30B153
C609 CHIP CERAMIC CAP. B K 0.068µF/50V CHD1JK30B683
C610 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C614# CAP METALLIZED FILM 0.22µF/275V/K CTA224PKR001
C616# CAP CERAMIC SAFETY 1000pF/250V E M KX CJMR102M42E1
C622 CHIP CERAMIC CAP.(2125) B K 10µF/6.3V CHE0KK30B106
C623 CHIP CERAMIC CAP.(1608) B K 4.7µF/6.3V CHD0KK30B475
C652 CAP ELE 470µF/25V/M/85 CED4710V8006
C653 CAP ELE 470µF/25V/M/85 CED4710V8006
C654 CAP ELE 470µF/16V/M/85 CEC4710V8006
C655 CAP ELE 470µF/16V/M/85 CEC4710V8006
C656 CAP ELE 1µF/50V/M/85 CEF1R00V8006
C657 CAP ELE 470µF/16V/M/85 CEC4710V8006
C660 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C666 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C671 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C672 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C1001 CAP ELE 470µF/25V/M/85 CED4710V8006
C1002 CAP ELE 470µF/25V/M/85 CED4710V8006
C1003 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1004 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1006 CAP ELE 47µF/100V/M/85 CEH4700V8006
C1007 CAP ELE 47µF/100V/M/85 CEH4700V8006
C1009 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1010 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1011 CHIP CERAMIC CAP.(3216) X7R K 1.0µF/100V CA2A105MR080
C1012 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1013 CHIP CERAMIC CAP.(1005) B K 1000pF/50V CHB1JK30B102
C1015 CHIP CERAMIC CAP.(1608) B K 0.047µF/25V CHD1EK30B473
C1016 CHIP CERAMIC CAP.(1005) B K 2200pF/50V CHB1JK30B222
C1017 CHIP CERAMIC CAP.(1608) B K 0.022µF/25V CHD1EK30B223
C1019 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1020 CHIP CERAMIC CAP.(1005) B K 2200pF/50V CHB1JK30B222
C1022 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
CONNECTORS
CN601# CONNECTOR S2P3-VH (LF)(SN) JCVHC02JG002
CN1001 PH CONNECTOR TOP 2P B2B-PH-K-S
(LF)(SN)
J3PHC02JG029
DIODES
D601 DIODE 1N5399BE NDL1001N5399
D602 DIODE 1N5399BE NDL1001N5399
D603 DIODE 1N5399BE NDL1001N5399
D604 DIODE 1N5399BE NDL1001N5399
D605 ZENER DIODE MM5Z4V3B ND1BMM5Z4V3B
D607# ZENER DIODE SMD TFZVTR27B QD1B00TFZV27
D608# DIODE ZENER 1ZB36BB NDWZ0001ZB36
D609 DIODE SCHOTTKY SMD CES520.L3F(D QD1Z00CES520
D610 DIODE SWITCHING SMD 1SS400ST(SOD-523) ND1Z1SS400ST
D621 DIODE SWITCHING SMD 1SS400ST(SOD-523) ND1Z1SS400ST
D623 ZENER DIODE MM5Z30B ND1B0MM5Z30B
D650 DIODE SCHOTTKY SB3150BH NDWZ00SB3150
D651 DIODE SCHOTTKY SB3150BH NDWZ00SB3150
D653 DIODE SCHOTTKY SB3A0BH NDWZ000SB3A0
D654 DIODE ZENER 1ZB20BB NDWZ0001ZB20
D655 DIODE SCHOTTKY SB3A0BH NDWZ000SB3A0
D656 DIODE FAST RECOVERY SMD GR1B ND1Z00GR1BTR
D657 ZENER DIODE MM5Z11B ND1B0MM5Z11B
D660 IC SHUNT REGULATOR SL431A-AT NSZBA0TAUK01
D661 DIODE SWITCHING SMD 1SS400ST(SOD-523) ND1Z1SS400ST
D1002 DIODE SCHOTTKY SMD SK210TD ND1Z0SK210TD
D1004 DIODE SWITCHING SMD 1SS400ST(SOD-523) ND1Z1SS400ST
D1005 DIODE SWITCHING SMD 1SS400ST(SOD-523) ND1Z1SS400ST
D1006 ZENER DIODE SMD TFZVTR30B QD1B00TFZV30
ICS
IC602# O-E DEVICE PHOTO COUPLER
TLP785F(D4FNBLLF(C
QPEL0TLP785F
IC1001 IC LED BACKLIGHT CONTROLLER BD9488F-
GE2/SOP/18P
QSCA0T0RM418
COILS
L601# LINE FILTER JLB24136 LLEG0Z0XB032
L1001 COIL POWER INDUCTORS DIP RP1315BNP-
101M/100µH
LLF1010SF013
L1002 COIL CHIP BEADS PZ2012D121-2R5T(F) LLF121SSN006
TRANSISTORS
Q601# FET MOS TK7P60W.RVQ(S QF2Z0TK7P60W
Q602# NPN TRANSISTOR SMD 2SC5344SY NQZY2SC5344S
Q621 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q650 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q653 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q1001 FET MOS SMD AP18T10AGH-HF NF2Z18T10AGH
Q1003 FET MOS SMD AP18T10AGH-HF NF2Z18T10AGH
RESISTORS
R601# RES. CARBON FILM J 1/2W J 1.2M RCX2125T1003
R602 RES CEMENT 5W J 2.7 RWJ2R7PAK007
R603 RES CHIP 3216 1/4W J 470k RRX4474HH034
R604 RES CHIP 3216 1/4W J 470k RRX4474HH034
R605 METAL OXIDE RES. 2W J 0.36 RN02R36ZU001
R606 RES CHIP 3216 1/4W J 220 RRX4221HH034
Ref. No. Description Part No.
