FUNAI LF320EM5F - Electrical Parts (Type D [LF320 EM4 a (Serial No.: ME1)])

2015/065/23 13-13 A4AFB_EL
Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Different parts from the original model
LF320EM4 A (Serial No. : DS1)
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT A4AFBMMA-003
C606 CERAMIC CAP. 680pF/2kV CA3D681PAN04
C607 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1016 Not Used
C1017 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
D1004 Not Used
D1006 ZENER DIODE MM5Z30B ND1B0MM5Z30B
IC1001 IC LED BACKLIGHT CONTROLLER BD9486F-
GE2/SOP/16P
QSCA0T0RM425
R602 RES CEMENT /T_ 5W J 2.7  RWJ2R7RYL001
R1003 CHIP RES.(1005) 1/16W 0  RRXG000HH005
R1009 RES CHIP 3216 1/4W F 0.82  RTR820RYL007
R1010 RES CHIP 3216 1/4W F 0.75  RTR750RYL007
R1011 RES CHIP 1005 1/16W F 2.2k  RTV2201HH004
R1013 RES CHIP 1005 1/16W F 36.0k  RTV3602HH004
R1014 RES CHIP 1005 1/16W F 24.0k  RTV2402HH004
R1020 RES CHIP 1005 1/16W F 360k  RTV3603HH004
R1021 RES CHIP 1005 1/16W F 240k  RTV2403HH004
R1022 RES CHIP 1005 1/16W F 22k  RTV2202HH004
R1023 RES CHIP 1608 1/10W J 10k  RRXA103HH013
R1024 RES CHIP 1608 1/10W J 10k  RRXA103HH013
R1030 RES CHIP 1005 1/16W J 120  RRXG121HH004
R1035 RES CHIP 3216 1/4W F 0.75  RTR750RYL007
R1037 Not Used
R1038 Not Used
FUNCTION CBA UNIT A4AFCMSW-001
