2015/06/26 13-23 A4AFE_EL
Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Different parts from the original model
LF320EM4 A (Serial No. : DS1)
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT A4AFEMMA-003
C606 CERAMIC CAP. 680pF/2kV CA3D681PAN04
C607 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
R602 RES CEMENT /T_ 5W J 2.7 RWJ2R7RYL001
R1011 RES CHIP 1005 1/16W F 24k RTV2402HH004
R1021 RES CHIP 1005 1/16W F 10k RTV1002HH004
R1022 RES CHIP 1005 1/16W F 22k RTV2202HH004
R1023 RES CHIP 3216 1/4W J 13k RRX4133HH034
R1024 RES CHIP 3216 1/4W J 2k RRX4202HH034
R1037 Not Used
R1038 Not Used
FUNCTION CBA UNIT A4AFCMSW-001
To Next Page
