TYPE C
PARTS LIST [LF320EM4 A (Serial No.: ME5)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Different parts from the original model
LF320EM4 A (Serial No. : DS1)
Ref.No. Description Parts No.
A15# RATING LABEL A4AFCUT ----------
A16 LOGO LABEL A3AF0UT ----------
A17 ENERGY GUIDE LABEL A3AFSUT ----------
B2-1 CLOTH(10X180XT0.5) A01FKUT 1EM432497
B5 PCB HOLDER A4AF0UH 2EMS00098A
CL3101 FFC WIRE ASSEMBLY 9PIN 9PIN/WHITE/
90MM
WX1A4AFFS213
SA1 STAND ASSEMBLY A31M0UT 1ESA34014
SSK1
STAND SCREW KIT A31M0UT(SCREW BIND
BLACK_NI +P-TITE M4X14.0)
1ESA34004
PAC K IN G
S1 CARTON A4AFBUT 2EMC00394A
S6 SET BAG A31F0UT 2EMC00088A
ACCESSORIES
X2# OWNERS MANUAL A4AFBUT 2EMN00189
X3 REMOCON UNIT FYT-WI002675 URMT32FNT004
X6 QUICK START GUIDE A4AFBUT 2EMN00190
LCD1# LCD PANEL ASSEMBLY U4DF0RA
A1 FRONT CABINET A3AF0UT 1EM030165
B2-1 CLOTH(10X180XT0.5) A01FKUT 1EM432497
CL3102 FFC WIRE ASSEMBLY 30PIN(W/SHIELD) 30P/
FFC/SHIELD/60MM
WX1A4AFDS101
