Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Different parts from the original model
LF320EM4 A (Serial No. : DS1)
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT A4AFSMMA-001
C606 CERAMIC CAP. 470pF/2kV CA3D471PAN04
C607 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C622 Not used
C650 CAP CHIP 3216 680pF/630V/C0G/J CHB6810TE009
C669 CHIP CERAMIC CAP.(1005) CH J 100pF/50V CHB1JJ3CH101
C1016 Not used
C1017 CAP CHIP CERAMIC (1608) B K 2.2µF/16V CHD1CK30B225
C1023 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1057 CHIP CERAMIC CAP.(1005) B K 1µF/6.3V CHB0KK30B105
D608 Not used
D608A# DIODE ZENER KDZTR36B QD1B000KDZ36
D654 Not used
D654A ZENER DIODE PTZTE2520B QD1B000PTZ20
D660 IC SHUNT REGULATOR AS431BNTR-E1 NSCA0TBCD041
D1004 Not used
D1006 ZENER DIODE MM5Z30B ND1B0MM5Z30B
D1006 ZENER DIODE EDZVT2R 30 B QD1B0EDZVT30
IC602 PHOTO COUPLER EL817S1(C)(TU)-F NP2C0EL817S1
IC1001 IC LED BACKLIGHT CONTROLLER BD9486F-
GE2/SOP/16P
QSCA0T0RM425
L601 COIL LINE FILTER LCL-2456 LLEG0ZMEK016
Q1051 PNP TRANSISTOR SMD 2SA1576UBTLQ QQ1Q2SA1576U
Q1052 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
R601# RES CARBON FILM /T_ 1/2W J 1.2 M RCJ125RYL001
R602 RES CEMENT /T_ 5W J 2.7 RWJ2R7RYL001
R605# METAL OXIDE RES. 2W J 0.36  RN02R36ZU001
R606 RES CHIP 3216 1/4W J 180 RRX4181HH034
R607 RES CHIP 3216 1/4W J 180 RRX4181HH034
R613 RES CHIP 3216 1/4W J 330 RRX4331HH034
R622 Not used
R650 RES CHIP 3216 1/4W J 2.2 RRX42R2HH034
R654 RES CHIP 3216 1/4W J 220 RRX4221HH034
R655 RES CHIP 3216 1/4W J 220 RRX4221HH034
R659 CHIP RES 1/16W F 68k RTV6802HH004
R660 RES CHIP 1005 1/16W F 3k RTV3001HH004
R661 RES CHIP 1005 1/16W F 6.8k RTV6801HH004
R667 RES CHIP 1005 1/16W J 33k RRXG333HH004
R674 Not used
R675 RES CHIP 1005 1/16W F 100k RTV1003HH004
R1001 Not used
R1002 RES CHIP 1608 1/10W J 39 RRXA390HH013
R1003 Not used
R1009 RES CHIP 3216 1/4W F 0.82 RTR820RYL007
R1011 RES CHIP 1005 1/16W F 2.2k RTV2201HH004
R1013 RES CHIP 1005 1/16W F 36.0k RTV3602HH004
R1014 RES CHIP 1005 1/16W F 24.0k RTV2402HH004
R1020 RES CHIP 1005 1/16W F 360k RTV3603HH004
R1021 RES CHIP 1005 1/16W F 240k RTV2403HH004
R1022 RES CHIP 1005 1/16W F 22k RTV2202HH004
R1023 RES CHIP 1608 1/10W J 10k RRXA103HH013
R1024 RES CHIP 1608 1/10W J 10k RRXA103HH013
R1030 RES CHIP 1005 1/16W J 120 RRXG121HH004
R1035 RES CHIP 3216 1/4W F 0.68 RTR680RYL007
R1036 Not used
R1037 Not used
R1038 Not used
R1051 CHIP RES.(1005) 1/16W J 10k RRXG103HH004
R1052 RES CHIP 1608 1/10W J 3.9k RRXA392HH013
R1053 CHIP RES.(1005) 1/16W J 10k RRXG103HH004
R1054 CHIP RES. 1/16W J 47k RRXG473HH004
R1055 RES CHIP 1608 1/10W J 3.9k RRXA392HH013
F602 FUSE TIME RAG 2010T2.5A1 PDG21B0W3252
FUNCTION CBA UNIT A4AFSMSW-001
Ref. No. Description Part No.
