APPENDIX
A-5
Plotter
MARKS/LINES COLOR (RED, YELLOW, GREEN, LIGHT BLUE,
PURPLE, BLUE, WHITE)
MARKS SHAPE ( )
LINES STYLE ( )
MARKS SIZE (LARGE, SMALL)
MENU Key
CHART OFFSET (offsets chart position.)
TRACKS
& MARKS
CONTROL
CHART SETUP
OWN SHIP TRACK DISP (ON, OFF)
OWN SHIP TRACK COLOR (RED, YELLOW, GREEN, LIGHT BLUE,
PURPLE, BLUE, WHITE)
TARGET TRACK DISPLAY (ON, OFF)
TARGET TRACK COLOR (RED, YELLOW, GREEN, LIGHT BLUE,
PURPLE, BLUE, WHITE)
INTERVAL (TIME, DISTANCE)
TIME INTERVAL (0 - 99m59s,10 seconds)
DISTANCE INTERVAL (0 - 99.99nm/km/sm, 0.1 nm)
MEMORY (TRACK & MARK) (0 - 8000 points, 2000 points)
TRACK soft key (RESUME, HALT)
LAT/LON GRID (RED, YELLOW, GREEN, LIGHT BLUE, PURPLE,
BLUE, WHITE, OFF)
TEXT INFORMATION (ON, OFF)
WAYPOINTS (LARGE, SMALL, OFF)
WAYPOINT NAMES (ON, OFF)
CHART BORDER LINES (ON, OFF)
LANDMASS (BRT, DIM, OFF, RED, YELLOW, GREEN,
LIGHT BLUE, PURPLE, BLUE, WHITE)
BACKGROUND (WHITE, BLACK)
NAVAIDS (ON, OFF)
LIGHT SECTOR INFO (ON, OFF)
OTHER SYMBOLS (OFF, RED, YELLOW, GREEN,
LIGHT BLUE, PURPLE, BLUE, WHITE)
MARKS SIZE (LARGE, SMALL)
CNTOUR LINE soft key
DEPTH < 10m (ON, OFF, RED)
DEPTH = 10m (ON, OFF, YELLOW)
DEPTH > 10m (ON, OFF, LIGHT BLUE)
DEPTH INFORMATION (ON, OFF, RED)
* Colors: RED, YELLOW, GREEN, LIGHT BLUE, PURPLE,
BLUE, WHITE
1
2
ERASE T & M soft key
ERASE ALL TRACKS
ERASE TRACKS BY AREA
ERASE TRACKS BY COLOR
ERASE TARGET TRACKS
ERASE ALL MARKS/LINES
ERASE MARKS BY AREA
MARK SETUP soft key
¡
✕
, , ,
= Default setting
CHART
DETAILS
(FURUNO,
NavCharts
TM
)
To Next Page
