19. RECORDING FUNCTIONS
19-2
19.1.2 Position events
The operator may manually save positions to the [Event] log by position or LOP (Line
of Position):
To record a position, get into the Voyage navigation mode or Voyage planning mode
then do as follows:
1. Click the [Record], [Event Log] and [POSN Event] buttons on the InstantAccess
bar to show the [Position Event] dialog box.
2. At the list box at the top of the dialog box, select position type.
[Manual]: Manual input of ship’s position. Go to step 4.
[LOP]: Latitude and longitude position of a fixed object at ship's position. Go to
step 5.
[Position]: Ship’s position fed from navigator selected. Go to step 3.
3. For [Position], click the [Record] button.
The position event mark appears at the ship’s position. The position is recorded
to the [Voyage] log.
Ship’s position fed from
navigator selected
Selected navigator
Navigator selected
Time of entry
1044
DGPS1
Position event mark
To Next Page
