FUTABA 12FG User Manual

10
<Before Use>
&RQWHQWVDQG7HFKQLFDO6SHFL¿FDWLRQV
6SHFL¿FDWLRQVDQGUDWLQJVDUHVXEMHFWWRFKDQJHZLWKRXWQRWLFH
Your 12FGA/12FGH/12FG includes the following components:
The set contents depend on the type of set.
• T12FG Transmitter, including RF module (MZ-DDS)
• R5114 Receiver
• HT2F1700B Ni-MH battery, NR4F1500 Ni-Cd battery
& Charger
• Switch harness
• Hex Wrench (1.5mm, 2.5mm)
• Neck strap
Transmitter T12FGA/T12FGH/T12FG
Operating system: 2-stick, 12+2 channels, PCM-G3,
synthesizer system
Transmitting frequency: 29, 35, 36, 40, 41, or 72 MHz
bands
Modulation: PCM-G3, PCM1024, or FM/PPM
switchable.
Power supply: 7.2V HT6F1700B Ni-MH battery
Current drain: 500mA average
Receiver R5114DPS
(PCM-G3, Synthesizer, Dual conversion)
Receiving frequency: 29, 35, 36, 40, 41, or 72 MHz
bands
Intermediate freq.: 10.7 MHz & 450 kHz
Power requirement: 4.8 V Ni-Cd battery
Current drain: 75 mA
Size: 37.7x52.3x16 mm (1.48x2.06x0.63 in.)
Weight: 32.5 g (1.15 oz.)
Channels: 14
Suggested Servos for use with your 12FG
Servo S9252 (Digital servo)
Control system: Pulse width control, 1.52 ms neutral
Power requirement: 4.8 V (from receiver)
Output torque: 6.6 kg-cm (91.7 oz.-in.) at 4.8V
Operating speed: 0.14 sec/60 at 4.8V
Size: 40.0 x 20.0 x 36.6 mm (1.57 x 0.79 x 1.44 in.)
Weight: 50 g (1.76 oz.)
Servo S9255 (Digital servo)
Control system: Pulse width control, 1.52 ms neutral
Power requirement: 4.8 V (from receiver)
Output torque: 9.0 kg-cm (125.0 oz.-in.) at 4.8V
Operating speed: 0.16 sec/60 at 4.8V
Size: 40.0 x 20.0 x 36.6 mm (1.57 x 0.79 x 1.44 in.)
Weight: 55 g (1.94 oz.)

FUTABA 12FG Specifications

General

Brand	FUTABA
Model	12FG
Category	Remote Control
Language	English
