18
<Before Use>
* Formatting starts. During formatting, the rectangular mark
at the center of the screen moves.
*When formatting is completed, a message is displayed.
Depending on the card capacity and speed, formatting may
take from tens of seconds to several minutes.
[IMPORTANT] Do not turn off the power
until the [FORMAT COMPLETED] message is
displayed.
4.End formatting by pushing the EDIT key.
SD card reader/writer
Saving model data and update files (released
from Futaba) into the SD card, you can use those
files on your T12FG transmitter. Equipment for
reading and writing SD cards is available at most
electronics stores.
Stored data
When you have a problem of saving or reading
data after a long period of use, please get a new SD
card.
*We do not have the responsibility of compensating any
failure or damage to the data stored in the memory card no
matter what the reason is. Be sure to keep a backup of your
important data in your SD card.
Connector/Plug
Ɣ'6&7UDLQHUƔ%DWWHU\FKDUJH
Connector for trainer function
When you use the trainer function, connect the
optional trainer cable between the transmitters for
teacher and student.
*You can set the trainer function on the Trainer Function
screen in the system menu.
Connector for DSC function
You can operate the transmitter without
transmitting radio waves by connecting the
transmitter and the receiver to the DSC cable.
*Please refer to the section "Connection between Receiver/
Servo"
Connector for battery charger
This is the connector for charging the Ni-
MH battery HT6F1700B that is installed in the
transmitter. Do not use any other chargers except
the attached special charger corresponding to Ni-
MH battery.
Danger
Do not connect any other chargers except the
special charger to this charging connector.
*If you take out the Ni-MH battery HT6F1700B from
the transmitter, you can use the optional quick charger
CR-2000 corresponding to Ni-MH battery.
To Next Page
