FUTABA GY701 - Governor On;Off Switch; Battery Failsafe Setting

G
OVERNOR
B
ASIC
S
ETTING
G
OVERNOR
B
ASIC
S
ETTING
50
51
(6) Governor on/off switch [default: Inhibit]
It selects the governor activate switch if addi-
tional switch is used. Pushing the SET (Data+)
key to be activated the function. The on/off
direction is changed by pushing the SET key
again. The function is inhibited by pushing the
RSET (Data-) key. This function is only available
at S.Bus connection. “Invalid” is displayed at
PWM connection.
Invalid display
(at PWM)
(7) Battery failsafe setting [default: Inhibit]
The governor gets into the failsafe mode at the
battery voltage is below 3.8 v when function is
activated, the governor is disactivated and the
throttle servo is moved to B/FS position at B/FS
condition. Move the throttle stick to idle position,
the B/FS condition is dis activated for 30 sec-
onds, and returned to B/FS after 30 seconds
passed.
Move the throttle stick to B/FS position as de-
sired, push set key to be finished the setting.
Pushing RSET is to be inhibited the function.
When governor turned on and off by switch
(S.BUS connection only)
Setting the switch to the ON position turns on
the governor. The following describes this op-
eration.
Governor can be turned
on and off by a switch.
• Switch set to on position and engine running at
60% or more of set speed

ON
• T h r o t t l e s t i c k s e t t o m a x i m u m s l o w
position

Remains ON
• Switch set to off position

OFF
(8) Yaw rate compensation [default: CW/
TOP]
It works the revolution compensation at the pir-
ouette. Set the mode to match the gyro install-
ing direction, either CW/TOP, CW/BOTM, CCW/
TOP, CCW/BOTM by pushing the Set key. Push-
ing the RSET key is to be inhibited the function.
At the governor only mode, this function is ig-
nored.
CW: clockwise
CCW: counter clockwise
TOP: normal side
BOTM: reverse side
