FUTABA T10PX - Method; When Charging for the Optional Lipo; Battery

20
●
LiPo battery installation
Install the Lipo spacer on the transmitter
and then the Lipo battery.
●
Battery type change
Be sure to change to LiPo battery type
in System Menu
→
Battery
Be sure to do it when using LiPo.
●
Charging LED
Lights red while charging. When charging
is complete, it lights up in green.
When Charging For The Optional LiPo Battery
To charge the battery, connect a type C USB cable to the Futaba optional USB AC adapter or a commercially
available USB AC adapter (USB-A type 5 V-2 A) from the Lipo dedicated charging port.
Charging LED
Red: Charging
Green: Full
Use a commercially
available USB charger
AC adapter
USB-A type 5 V-2 A
USB Cable
Battery charging port
LiPo Battery charging port
Lipo spacer
Do not charge the Lipo battery from the charging port on the top back of
the transmitter
There is a risk of explosion or fire, which is very dangerous.
Do not charge the Lipo
battery from here ！
LED
Attention to the direction!
Battery charging port, LED
on this side.
Lipo Battery LT2F2000B Replacement Method
7.26
Warning
Do not charge the Lipo battery with LBC-34/38D P or ICS LF-01.
There is a risk of explosion or fire, which is very dangerous.
Connect to the connector
on this side.
Store the battery wiring in
this groove.
