Explanation Of Symbols
Warning
Special attention should be paid before turning on the system while other cars are running or other air-
planes are flying because the 2.4GHz RC system could potentially affect them.
Be sure to set the Fail-safe function.
Caution
Be sure to use the T10PX receiver setting and the servo to be used under predetermined conditions.
Under other conditions, the set will not operate, or the specified performance will not be displayed even if it operates. In addition, it
may cause servo trouble. Futaba will not be responsible for problems caused by the use of other than genuine Futaba parts. Use the
parts specified in the instruction manual and catalog.
For Your Safety As Well As That Of Others
Use this product in a safe manner. Please observe the following safety precautions at all times.
For safety’s sake, pay special attention whenever you see the marks shown here.
For safe use
Symbols: : Prohibited : Mandatory
2.4GHz System Precautions
Receiver Servo Mode Precautions
●
For servos for which the operation mode can be set, change the servo operation mode according to the system to
be used. If the operating modes of the system and servo are different, it will fail.
●
Use SR servo for SR mode.
●
When the SR mode is ON, it is exclusively for our SR compatible servo. Using a servo other than the SR
compatible servo may cause the servo or receiver to malfunction.
●
If a normal servo is connected to a CH with SR mode ON, there is a risk of damage.
●
Do not connect SR servo (set to SR mode) and analog servo in digital servo mode.
●
Do not connect SR servo (set to SR mode) in analog servo mode.
●
SR servo can be used digital or analog when set to normal mode.
●
Connecting an SR mode compatible servo set to SR mode to the S (S.BUS2 port) may cause malfunction of the
servo or receiver.
●
Refer to country distributor WEB for detailed the "S. BUS servo menu" and the "SR mode setting"
explanation.
●
Receiver battery: Matched to the ratings of the receiver and connected servo (dry cell battery cannot be used).
●
Fail-safe Unit cannot be used because the system is different. Use the fail-safe function of the transmitter.
Danger
Warning
Caution
Procedures which may lead to dangerous conditions and cause death/serious injury if not carried out properly.
Procedures which may lead to a dangerous condition or cause death or serious injury to the user if not carried out properly, or
procedures where the probability of superficial injury or physical damage is high.
Procedures where the possibility of serious injury to the user is small, but there is a danger of injury, or physical damage, if
not carried out properly
