3. H-Links Width Adjustment (Both Front and Rear)
a. To adjust, loosen all screws (A) on both sides of the H-Links frame (B)
cross tubes.
b. Slide the H-Link frame to the desired width using the pre-set holes in both
the H-Link frame cross tube and center tube (C).
c. Tighten screws (A).
3
