Gallagher W810 v2 User Manual

 3E2364WeighScaleW810v2UserManual

Page6

Usinganexternal12voltbattery
TochargetheWeighScale'sinternalbatteryusinganexternal12voltbattery,
followthesesteps:
1. ConnectthesuppliedblackandredbatteryleadstotheWeighScale.
2. Connecttheotherendofthebatteryleadstothe12voltbattery.

ConnecttheRedcliptothePositiveterminal.
ConnecttheBlackcliptotheNegativeterminal.
3. OpentheWeighScalecaseandmakesurethebatterychargeicon 
onthemainscreenisflashing.Thisindicatesthatthebatteryischargingand
willbedisplayedwhethertheWeighScaleisturnedonoroff.
Batterychargestatus
ThebatteryicondisplaysinthebottomleftcorneroftheWeighScale'supper
screen.
Itisimportanttonotethatthebatteryiconwillonlyevershowtheactual
amountofchargeleftinthebatterywhentheWeighScaleisturnedonand
disconnectedfromexternalpower.
FullyCharged BatteryIconbarsarealldisplayedconstantly.
Partially
Charged

BatteryIconshowsfirstfourbarsconstantly.
BatteryFlat

NoBatteryIconbarsaredisplayed.
WhentheWeighScaleisconnectedtotheexternalpowersupplythebattery
iconwilldisplaythechargingstatus.
Charging

BatteryIconshowsallthebarsconstantlyfilling
andthendisappearing.

Lowbatterywarning
Whenthechargeremaininginthebatterydropstoaverylowlevel,thebattery
chargeiconontheWeighScalewillstarttoflashandfourbeepswillsoundevery
30seconds.Afterabout15minutes,theWeighScalewillshutdown.
