 Page5

POWERANDBATTERIES
Duringaweighingsession,theWeighScalecanbepoweredbyitsinternal
batteryaloneorbyitsinternalbatteryandeitherthebatterychargeroran
external12voltbattery.
ThebatterychargerconnectsbetweenanACoutletandtheWeighScale.
Ifeitherthebatterychargeroranexternal12voltbatteryisconnectedtothe
WeighScale,theWeighScale'sinternalbatterywillbechargedwhiletheWeigh
Scaleisinuse.
Foroptimumperformance,switchofftheWeighScaleandchargeitsinternal
batteryovernight.Whenfullycharged,theinternalbatteryonitsownwill
powertheWeighScalecontinuouslyforaminimumofeighthours.
BatterylifemaybereducediftheWeighScaleisbeingusedtopoweran
ElectronicIDreader.
Chargingthebattery
ThebatteryintheWeighScalecanberechargedusingeitherabatterychargeror
anexternal12voltbattery.
Rechargingthebatterywilltakeuptosixteenhoursdependingonthelevelof
chargealreadyinthebattery.TheWeighScalecanbeinuseorcanbeswitched
offwhilethebatteryisbeingcharged.
Usingthebatterycharger
Tochargethebatteryusingthebatterycharger,followthesesteps:
1. ConnecttheleadbetweenthebatterychargerandtheWeighScale.

2. PlugthebatterychargerintoanACoutletandswitchon.
3. OpentheWeighScalecaseandmakesurethebatterychargeicon

onthemainscreenisflashing.Thisindicatesthatthebatteryischargingand
willbedisplayedwhethertheWeighScaleisturnedonoroff.
