Gallagher W810 v2 - Connecting the Weigh Scale to the Loadbars

3E2364WeighScaleW810v2UserManual

 Page49

ConnectingtheWeighScaletotheloadbars
Beforeyoubegintheweighingsession,completethefollowingsteps:
1. OpentheWeighScalecase.
2. MounttheWeighScaleonaflatsurfaceorclipitontotheWeighScale
bracket.


3. Ensureallrequiredaccessoriesareconnectedandsetup,forexample:
 Loadbars
 Drafters
 ElectronicIDreaders
4. DetermineifyourequireadditionalpowerfortheWeighScale.
EitherconnecttoanACoutletviathebatterychargerorconnecttoa12volt
battery.
Ifyouare
notconnectingtoanexternalpowersource,theWeighScale's
internalbatteryshouldbefullycharged.SeeChargingtheBattery(p5),if
required.
5. Checkandupdatethesetupoptions,asrequired.SeeSetup(p10)for
furtherdetails.

