3E2364WeighScaleW810v2UserManual



 Page3



INSTALLATION

InstallingtheWeighScalebracket

Thebracketcanbemountedonaflatverticalsurface,oronaroundpost.

Tomountthebracketona

flatverticalsurface,for

exampleasquarepostor

board,usetheouterholes.

Tomountthebracketona

roundpost,usetheinner

holes.



Don'tmounttheWeighScalebracketontheweighingcrateorchute.
