User module »DP-HR-U-CON-2-Fiber-DH«
173 · Target and user modules (DP-HR-U)
Technical data
DP-HR-U-CON-2-FIBER-DH
Interfaces to console Video: 2 × DisplayPort
Keyboard and mouse signals 2 × PS/2 socket
3 × USB-A
Audio: 2 × 3.5 mm jack plug
USB 2.0: 4 × USB-A socket
Tradeswitch-LED: 1 × D-SUB 9 socket
Data transmission to
the matrix switch
Interface: 2 × LC-Duplex socket
Transmission distance: DVI-CPU-Fiber-UC(M)
Max. 100 Meter (62,5μ/125μ),
Max. 200 Meter (50μ/125μ OM2)
Max. 400 Meter (50μ/125μ OM3)
DVI-CPU-Fiber-UC(S)
Max. 5.000 Meter (9μ/125μ OS1)
DVI-CPU-Fiber-UC(S+)
Max. 10.000 Meter (9μ/125μ OS1)
Audio
DisplayPort Digital
Transmission type: 2 channel LPCM, stereo
Resolutions: 16/20/24 bit
Sampling rates: up to 48 kHz
Audio Transmission type: transparent, bidirectional
Resolution: 24 bits
Refresh rate: 96 kHz
Bandwidth: 22 kHz
USB Specification: USB 2.0
Transmission type: transparent
Transmission rate: Max. 16 Mbit/s
Video Format: DisplayPort (DP 1.1a)
Colour depth: 24 Bit
Video bandwidth: 25 to 300 MP/s (Channel 1)
25 to 165 MP/s (Channel 2)
Max. 330 MP/s (total)
Vertical frequency: 24 Hz to 120 Hz
Horizontal frequency: 25 kHz to 135 kHz
