G&D DP-HR-CPU User Manual

User module »DP-HR-U-CON-2-Fiber-DH«
Target and user modules (DP-HR-U) · 174
Video Examplary resolutions: Channel 1:
 2048 × 2048 @ 60 Hz (2K×2K)
 2048 × 2160 @ 60 Hz
 2560 × 1600 @ 60 Hz
 3840 × 2160 @ 30 Hz (Ultra HD)
 4096 × 2160 @ 30 Hz (4K)
 1920 × 1080 (50 or 60 Hz)
 1440 × 576i (50 Hz)
 1440 × 480i (60 Hz)
Channel 2:
 1920 × 1200 @ 60 Hz
 1280 × 1024 @ 85 Hz
 1080p60 (Full HD)
 640 × 480 @ 60 Hz
 Further VESA and CTA standardised
resolutions possible within video
bandwidth/pixel rate and
horizontal/vertical frequency.
DDC/CI: The device supports monitors with a
DDC/CI function. The DDC information
are transparently forwarded to the moni
-
tor to support a maximum number of
monitors. However, the support cannot
be guaranteed for all monitor models.
Main power supply Type: Internal power pack
Connector: 1 × IEC plug (IEC-320 C14)
Power input: 100 - 240 VAC; 0.6 A - 0.3 A
Redundant
power supply
Type: External power pack
Connector: 1 × Mini-DIN 4-Buchse
Power input: 12 VDC; 2.5A
Housing Material: Anodised aluminium
Dimensions (W × H × D): 210 × 44 × 210 mm
Operating
environment
Temperature: +5 °C to +45 °C
Air humidity: 20 % to 80 %, non-condensing
Storage
environment
Temperature: -20°C to +55°C
Air humidity: 15 % to 85 %, non-condensing
Conformity CE, EAC, FCC Class B, RoHS
DP-HR-U-CON-2-FIBER-DH
