Target module »DP-HR-U-CPU-Fiber-MC2-UC«
Target and user modules (DP-HR-U) · 50
Connecting the second first matrix switch
Trans. 2|Channel 1|Tx: Insert the LC plug of a compatible optical fibre cable. Connect
the other end of the cable to the
Rx interface of a Dynamic Port provided at the second
matrix switch.
Trans. 2|Channel 1|Rx: Insert the LC plug of a compatible optical fibre cable. Connect
the other end of the cable to the
Tx interface of the same Dynamic Port provided at the
second matrix switch.
Trans. 2|Channel 2|Tx: Insert the LC plug of a compatible optical fibre cable. Connect
the other end of the cable to the
Rx interface of another Dynamic Port provided at the
second matrix switch.
Trans. 2|Channel 2|Rx: Insert the LC plug of a compatible optical fibre cable. Connect
the other end of the cable to the
Tx interface of the same Dynamic Port provided at the
second matrix switch.
Power supply
Power In: Insert the power pack’s connection cable to this interface.
Start-up
Connect the power cable to the power pack and a power socket.
The target module starts as soon as it is supplied with power. During start-up, the
channels are automatically grouped (see below).
Automatic grouping of channels
When operating the target module for the first time, the matrix switch recognises the
main channel and the target module’s additional channel. The channels are automat
-
ically added to a channel group.
ADVICE:
You can also connect the target module directly to up to two compatible
user modules.
NOTE:
You can adjust any manually or automatically created channel group.
More information about channel groups is given in the separate manuals of the
matrix switch web applications.
