Page 87
490X Engineer’s Reference Guide
25) Press Yes. The display will show:-
26) Press No until the required setting is displayed
then press Yes. The display will show:-
27) Press No. The display will show:-
28) Press Yes. The display will show:-
29) Press No until the required setting is displayed
then press Yes. The display will show:-
30) Press No. The display will show:-
31) Press Yes. The display will show:-
32) Press No twice. The display will show:-
33) Enter the time required followed by Yes.
The display will show:-
Bell Trigger
= Unconfirmed
Program Confirm
Bell Mode ?
Program Confirm
Strobe Mode ?
Program Confirm
Strobe Mode ?
Program Confirm
Start Delay ?
Program Confirm
Start Delay ?
Start Delay
= 000m
Start Delay
> _ _ _m
Strobe Trigger
= Unconfirmed
