190-02072-00 Rev. B 25
Installation Manual
Installation Manual Pilot's Guide Index
0
0
3X
.150±.003 3.81±0.08
3.155
3.125
80.14
79.38
2X 1.237±.005 31.4±0.13 1.237±.005 31.4±0.13
1.237±.005
31.4±0.13
2X 1.237±.005 31.4±0.13
Cut out panel
to inside line
Figure 1-12 G5 Panel Cutout Measurements (Not to Scale)
