GPSMAP 12x2 Specifications
Dimensions (W x H x D) 358.8 x 226.8 x 82.7mm (14
1
/
8
x 8
15
/
16
x 3
4
/
16
in.)
Dimensions on bail mount(W x H x D) 390.7 x 242.3 x 97.5mm (15
3
/
8
x 9
9
/
16
x 3
13
/
16
in.)
Display size (W x H)
262.1 × 164.2mm (10
5
/
16
x 6
7
/
16
in.)
12.1in. diagonal
Display resolution WXGA, 1280 x 800 pixels
Weight 2.34kg (5.2lb.)
Compass-safe distance 65cm (25.5in.)
Temperature range From -15° to 50°C (from 5° to 122°F)
Material Polycarbonate plastic and die-cast aluminum
Water rating IEC 60529 IPX7
3
Fuse 6A, 125V fast-acting
Input voltage From 10 to 32Vdc
Max. power usage at 10Vdc 34.8W
Typical current draw at 12Vdc 2.2A
Max. current draw at 12Vdc 2.9A
NMEA 2000 LEN @ 9Vdc 2
NMEA 2000 draw 75mA max.
Max. waypoints 5,000
Max. routes 100
Max. active track points 50,000 points, 50 saved tracks
Memory card 2 SD card slots; 32GB max. card size
Wireless frequency and protocols
Wi‑Fi, ANT, and Bluetooth technologies
2.4GHz @ 15.26dBm nominal
Sonar Models Specifications
Sonar frequencies
4
Traditional: 50/200, 77/200, 83/200kHz
Single Channel CHIRP: from 40 to 250kHz
Garmin ClearVü CHIRP: 260/455/800kHz
Sonar transmit power (RMS)
5
CHIRP: 1000W
Garmin ClearVü and SideVü CHIRP: 500W
Sonar depth
6
5,000ft. at 1kW
3
The device withstands incidental exposure to water of up to 1m for up to 30min. For more information, go to www.garmin.com/waterrating.
4
Dependent upon the transducer.
5
Dependent upon the transducer rating and depth.
6
Dependent upon the transducer, water salinity, bottom type, and other water conditions.
